Full Specs & Features
Depth : 28'
Height : 27'
Width : 16'
First Floor: 448 sq/ft
Second Floor: 448 sq/ft
Primary Pitch : 12:12
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Formal Living Room / Parlor
Covered Front Porch
40 sq/ft width 5' x depth 8' 2"
117 sq/ft width 13' x depth 9'
17 sq/ft width 3' x depth 5' 8"
137 sq/ft width 15' 4" x depth 9'
173 sq/ft width 15' 4" x depth 11' 4"
147 sq/ft width 13' x depth 11' 4"
Porch - Front:
width 0" x depth 5' 4"
Porch - Rear:
width 0" x depth 3' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
