Key Specs
2218
sq ft
3
Beds
2.5
Baths
2
Floors
3
Garages
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 1016-107
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 52' 2"
Height : 27' 6"
Width : 44'
Area
Basement Unfinished: 1078 sq/ft
First Floor: 1228 sq/ft height 9'
Garage: 657 sq/ft
Porch: 30 sq/ft
Second Floor: 990 sq/ft height 8'
Storage: 140 sq/ft
Roof
Primary Pitch : 11:12
Roof Framing : Combination Truss/Conventional
Roof Type : Composition
Secondary Pitch : 4:12
Exterior Wall Framing
Exterior Wall Finish : Shingle/Stone
Framing : Wood - 2x6
Bedroom Features
Fireplace
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Mud Room
Open Floor Plan
Storage Area
Vaulted / Cathedral Ceilings
Garage Features
Front Entry Garage
Rear Entry Garage
Outdoor Spaces
Courtyard
Covered Front Porch
Rooms
Bedroom 2:
width 12' x depth 13'
Bedroom 3:
width 12' x depth 13'
Den:
width 15' 2" x depth 12'
Dining:
width 12' 4" x depth 9' 3"
Garage:
width 20' 6" x depth 19' 3"
Garage 2:
width 11' 2" x depth 19' 10"
Great Room:
width 22' 2" x depth 19' 5"
Kitchen:
width 10' 3" x depth 12' 2"
Master Bedroom:
width 12' x depth 18' 2"
Porch Front:
30 sq/ft
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1010.00
Foundation
$0.00
Framing
$0.00
Additional Options
$100.00
$39.00
$100.00
$60.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
