Key Specs
6405
sq ft
5
Beds
6.5
Baths
2
Floors
4
Garages
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
Use Code CTBBF (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 417-447
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 113'
Width : 104' 6"
Area
First Floor: 5251 sq/ft
Garage: 1314 sq/ft
Second Floor: 1154 sq/ft
Ceiling
Main Ceiling : 12'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 6:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Concrete block
Bedroom Features
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Media Room
Storage Area
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
216 sq/ft width 18' x depth 12'
Bedroom 3:
221 sq/ft width 18' x depth 12' 4"
Bedroom 4:
204 sq/ft width 17' x depth 12'
Bedroom 5:
260 sq/ft width 15' 4" x depth 17'
Den:
204 sq/ft width 11' 10" x depth 17' 3"
Dining Room:
239 sq/ft width 13' 4" x depth 18'
Exercise Room:
186 sq/ft width 16' 6" x depth 11' 4"
Family Room:
437 sq/ft width 19' x depth 23'
Garage:
1159 sq/ft width 47' 8" x depth 24' 4"
Kitchen:
336 sq/ft width 18' x depth 18' 8"
Laundry Room:
98 sq/ft width 8' 4" x depth 11' 10"
Living Room:
378 sq/ft width 18' x depth 21'
Master Bathroom:
439 sq/ft width 22' 2" x depth 19' 10"
Master Bedroom:
412 sq/ft width 26' 1" x depth 15' 10"
Media Room:
334 sq/ft width 19' 8" x depth 17'
Sitting Area:
81 sq/ft width 9' x depth 9'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$3150.00
$6300.00
$1000.00
Foundation
$0.00
Additional Options
$100.00
$39.00
$200.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
