Plan Description


This plan extends for just over 6,000 square feet, sprawling with cozy sections throughout. An arched entryway guides you toward coffered ceilings in the foyer, dining room, and library. Straight ahead is the living room with bay window, providing views of the covered patio. The spacious island kitchen lies to the left, open to the family room and nook for casual dining. The entire right wing of the floor is devoted to the master suite, and includes a lavish bath and exercise room. To the left of the plan are two bedrooms with full private baths. A kid's room and full bath and bonus space are on the second level. Two double garages ensure the safety of the family fleet.

Full Specs & Features


Dimension

Depth : 103' 10"

Height : 29'

Width : 95'

Area

First Floor: 5204 sq/ft height 8'

Second Floor: 1055 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 8:12

Roof Framing : Truss

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Stone/Stucco

Framing : Block

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Main Floor Master Bedroom

Split Bedrooms

Kitchen Features

Breakfast Nook

Kitchen Island

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Exercise Room

Family Room Keeping Room

Main Floor Laundry

Outdoor Spaces

Courtyard

Covered Rear Porch

Outdoor Fireplace

Rooms

3rd BR Closet:

37 sq/ft width 5' 6" x depth 6' 10"

Bathroom 2:

56 sq/ft width 11' x depth 5' 2"

Bathroom 3:

44 sq/ft width 5' x depth 8' 10"

Bedroom 2:

173 sq/ft width 13' x depth 13' 4"

Bedroom 2 Closet:

21 sq/ft width 10' 6" x depth 2'

Bedroom 3:

193 sq/ft width 14' 6" x depth 13' 4"

Bedroom 3 Closet:

21 sq/ft width 10' 6" x depth 2'

Bonus Room - Finished:

360 sq/ft width 15' 8" x depth 23'

Breakfast Room:

132 sq/ft width 13' x depth 10' 2"

Den/Office or Bedroom 1:

195 sq/ft width 13' 4" x depth 14' 8"

Dining Room:

225 sq/ft width 15' x depth 15'

Exercise Room:

213 sq/ft width 10' x depth 21' 4"

Foyer:

73 sq/ft width 8' 8" x depth 8' 6"

Game Room:

292 sq/ft width 15' 8" x depth 18' 8"

Garage:

590 sq/ft width 26' 10" x depth 22'

Garage Two:

484 sq/ft width 22' x depth 22'

Gathering Room:

457 sq/ft width 17' 2" x depth 26' 8"

Kitchen:

278 sq/ft width 18' 2" x depth 15' 4"

Laundry Room:

128 sq/ft width 14' 3" x depth 9'

Living Room:

257 sq/ft width 15' 2" x depth 17'

Master Bathroom:

403 sq/ft width 22' 10" x depth 17' 8"

Master Bedroom:

383 sq/ft width 18' x depth 21' 4"

Master Closet:

188 sq/ft width 16' 8" x depth 11' 4"

Parlor:

270 sq/ft width 18' x depth 15'

Porch - Rear:

2384 sq/ft width 65' 4" x depth 36' 6"

Powder Room:

69 sq/ft width 10' 9" x depth 6' 6"

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
