Full Specs & Features
Depth : 69'
Height : 32'
Width : 50'
First Floor: 2053 sq/ft height 10'
Garage: 524 sq/ft
Porch: 199 sq/ft
Second Floor: 598 sq/ft height 9'
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Primary Pitch : 16:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : 2"x4"
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
Family Room Keeping Room
Great Room Living Room
Friend S Entry
Suited For Narrow Lot
Suited For View Lot
Covered Front Porch
Covered Rear Porch
Jack & Jill Bath
141 sq/ft width 11' 9" x depth 12'
168 sq/ft width 12' x depth 14'
168 sq/ft width 14' x depth 12'
122 sq/ft width 12' 3" x depth 10'
504 sq/ft width 24' 6" x depth 20' 7"
196 sq/ft width 12' 3" x depth 16'
175 sq/ft width 10' 4" x depth 17'
188 sq/ft width 13' x depth 14' 6"
220 sq/ft width 16' x depth 13' 9"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
