PLAN 406-9657
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 85' 4"
Height : 22' 10"
Width : 45' 6"
Area
Garage : 671 sq/ft
Main Floor : 1782 sq/ft
Porch : 311 sq/ft
Ceiling
Main Ceiling : 10'
Roof
Primary Pitch : 12/12
Roof Framing : Stick
Secondary Pitch : 4/11
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Main Floor Laundry
Mud Room
Storage Area
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Economical To Build
What's Included In This Plan Set
- The first sheet is the cover sheet which outline the Design Criteria and Construction Notes, such as general site, foundation, framing and mechanical notes
- The second sheet is typically the front and side elevation drawn to 1/4" scale.
- The third sheet is the rear and side elevation drawn to 1/4" scale.
- The foundation of your choice (slab or crawlspace ). Floor Plan 1/4" Scale
- Detail and Section Page
- Cabinet elevations & Roof Plan
- Electrical Plan
- Foundation Details
Plan Set
$1160.00
$1355.00
$1530.00
$1660.00
$2065.00
$2565.00
Foundation
$0.00
$350.00
Framing
$0.00
Additional Options
$255.00
$165.00
$295.00
$39.00
$165.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
