PLAN 47-809

Key Specs

1760
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.

Modify This Plan

Plan Description

This brick design offers a covered rail porch that provides a weather-protected entry to the home. The vaulted foyer carries its ceiling detail into the living room, where there is a fireplace and double-door access to the rear patio. A screened porch adds space to the breakfast room and allows for protected casual outdoor dining. Look no further than the master bedroom for true luxury.

Floor Plans

Floor Plan - Main Floor Plan

Reverse

Full Specs & Features

Dimension

Depth : 46'
Height : 24'
Width : 68'

Area

First Floor: 1760 sq/ft height 9'

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 9:12
Roof Framing : Truss

Exterior Wall Framing

Exterior Wall Finish : Siding
Framing : Wood - 2x6

Bedroom Features

Fireplace
Formal Dining Room
Formal Living Room / Parlor

Additional Room Features

Great Room Living Room

Outdoor Spaces

Covered Rear Porch

Rooms

3rd BR Closet:

15 sq/ft width 2' x depth 7' 8"

Basement Foundation:

679 sq/ft width 11' 4" x depth 60'

Bedroom 2:

127 sq/ft width 12' 6" x depth 10' 2"

Bedroom 2 Closet:

15 sq/ft width 2' x depth 7' 10"

Bedroom 3:

117 sq/ft width 10' 8" x depth 11'

Bedroom 3 Closet:

15 sq/ft width 2' x depth 7' 10"

Breakfast Room:

101 sq/ft width 10' 8" x depth 9' 6"

Crawlspace Foundation:

2659 sq/ft width 44' 4" x depth 60'

Dining Room:

137 sq/ft width 11' x depth 12' 6"

Foyer:

63 sq/ft width 8' 10" x depth 7' 2"

Garage:

408 sq/ft width 21' 6" x depth 19'

Gathering Room:

304 sq/ft width 19' x depth 16'

Hall Bathroom:

45 sq/ft width 9' x depth 5'

Hall Closet:

6 sq/ft width 3' x depth 2'

Kitchen:

167 sq/ft width 15' x depth 11' 2"

Master Bathroom:

93 sq/ft width 10' x depth 9' 4"

Master Bedroom:

195 sq/ft width 15' x depth 13'

Porch - Front:

90 sq/ft width 4' 8" x depth 19' 4"

Porch - Rear:

93 sq/ft width 7' 6" x depth 12' 6"

Utility Room:

45 sq/ft width 7' x depth 6' 6"

Walk-In Closet:

51 sq/ft width 5' 6" x depth 9' 4"

What's Included In This Plan Set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

» See important information before purchasing.

Plan Set

PDF Set : $880.00	PDF plan sets are best for fast electronic delivery and inexpensive local printing.
5 Copy Set : $990.00	5 printed plan sets mailed to you.
8 Copy Set : $1100.00	8 printed plan sets mailed to you.
Reproducible Set : $1100.00	For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set : $1760.00	For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Basement: $0.00	Ideal for level lot, lower level of home partially or fully underground.
Crawlspace: $0.00	Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Daylight Basement: $275.00	Ideal for sloping lot, lower level of home partially underground.
Slab: $275.00	Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x6:
$0.00

Wood 2x6

Additional Options

Additional Construction Sets : $60.00	Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design : $100.00	Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide : $39.00	Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Home Furniture Planner : $19.00	This fun visual aid lets you peel-and-stick furniture on a generic layout to plan out spacing.
Lighting Design : $100.00	Receive an overlay sheet with suggested placement of lighting fixtures.
Material List : $85.00	A list of building supplies needed to construct the infrastructure of your new house.
Mirror Reversed Sets : $60.00	Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Right-Reading Reverse : $175.00	Choose this option to reverse your plans and to have the text and dimensions readable.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
