Plan Description


This beach design floor plan is 6833 sq ft and has 5 bedrooms and 6 bathrooms.

Full Specs & Features


Dimension

Depth : 112' 6"

Height : 32'

Width : 73' 4"

Area

Garage : 1028 sq/ft

Main Floor : 4268 sq/ft

Patios : 1007 sq/ft

Porch : 124 sq/ft

Upper Floor : 2565 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : coffer w/beams, flat, vaulted T&G w/beams, tray w/beams, flat, vaulted, double coffer

Main Ceiling : 12'

Roof

Primary Pitch : 7:12

Roof Framing : Manufactured trusses

Roof Type : Cement flat Tile

Secondary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : ICF

Bedroom Features

Guest Suite

Main Floor Bedrooms

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room

Loft

Main Floor Laundry

Master Sitting Area

Storage Area

Workshop

Garage Features

Front Entry Garage

Oversized Garage

Side Entry Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Balcony

Covered Front Porch

Covered Rear Porch

Outdoor Kitchen Grill

More

Jack & Jill Bath

Wheelchair Adaptable

What's Included In This Plan Set


Please call if building in Lee and Collier Counties of Florida, restrictions apply.

    Elevations - Drawn at 1/8" to 1/4" Scale, and Includes:
    • Material Labels
    • Foor-to-Floor Heights
    • Roof Slope Indicators
    Floor Plans - Drawn at 1/8" to 1/4" Scale and Includes:
    • Door and Window Sizes
    • Completely Dimensioned Floor Plan
    • Room Labels and Interior Room Sizes
    • Electrical Layouts
    • Building Section Markers
    • All Electrical Outlets, Fixtures, and Switching
    • Floor and Deck Joist Size and Spacing
    • Rough-in Plumbing Location (if applicable)
    • Mechanical Equipment Locations (if applicable)
    • Electrical Locations (if applicable)
    Roof Design Plan - Drawn at 1/8" to 1/4" scale and Includes:
    • All Beam and Header Heights and Locations
    • All Hips, Gables, Ridges and Valleys
    • Building Section Markers
    Building Sections - Drawn at 1/8" to 1/4" Scale and Includes:
    • Floor Joist Size and Spacing
    • Floor-to-Floor Heights
    • Non-Typical Plate Heights Indicated
    Typical Wall Sections - Drawn at 1/8" to 1/2" Scale and Includes
    • All Labels Indicating Wall Construction
    • Foundation Wall Thickness and Reinforcing
    • Insulation Type and Thickness
    Miscellaneous Notes and Details
    • Miscellaneous General Notes
    • Stairway details (if applicable)
    Please Note: This design will not come with a foundation. The foundation should be created by a local structural engineer.

» See important information before purchasing.
Questions? Call 1-866-445-9085

Plan Set

CAD Set:
$7428.56
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
PDF Set:
$7428.56
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set:
$7428.56
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

Foundation

Crawlspace:
$0.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.

Additional Options

Audio Video Design:
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide:
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
