PLAN 76-129

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.

Modify This Plan

Plan Description


This captivating Spanish Colonial villa includes three levels of living space to accommodate seven bedrooms and seven full baths---an elevator accesses every level. Enter on the ground floor to find a game room, guest suite and pool area. Upstairs, the main level supports a comfortable living room, with a cozy fireplace and French doors to the balcony. The kitchen opens to a nook, bathed in light. Three family bedrooms and a guest suite---each with private baths---complete the level. One more flight of stairs leads to the upper living areas, comprising an inviting family room, formal dining room and ancillary kitchen, private study, and two bedrooms. The master suite is a decadent retreat, with two private balconies, a fireplace-warmed bath, a recessed whirlpool tub and a compartmented toilet and bidet.

Full Specs & Features


Dimension

Depth : 75' 2"

Height : 37'

Width : 74' 10"

Area

First Floor: 929 sq/ft height 9'

Second Floor: 2092 sq/ft

Third Floor: 2437 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 5:12

Roof Framing : Conventional

Roof Type : Tile

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Wood - 2x6

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Guest Suite

Kitchen Features

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Hobby Rec Room Game Room

Loft

Upstairs Laundry

Garage Features

Side Entry Garage

Outdoor Spaces

Balcony

Courtyard

Covered Front Porch

Grill Deck Sundeck

Rooms

3rd BR Closet:

15 sq/ft width 6' 10" x depth 2' 4"

Bathroom 2:

50 sq/ft width 9' 6" x depth 5' 4"

Bathroom 3:

74 sq/ft width 8' x depth 9' 4"

Bedroom 2:

178 sq/ft width 12' 4" x depth 14' 6"

Bedroom 2 Closet:

182 sq/ft width 12' 4" x depth 14' 10"

Bedroom 3:

211 sq/ft width 12' 10" x depth 16' 6"

Bedroom 3 Closet:

172 sq/ft width 12' 4" x depth 14'

Bedroom 4:

195 sq/ft width 14' 6" x depth 13' 6"

Bedroom 4 Closet:

11 sq/ft width 2' 4" x depth 5'

Bedroom 5:

197 sq/ft width 15' 10" x depth 12' 6"

Dining Room:

181 sq/ft width 14' 6" x depth 12' 6"

Foyer:

40 sq/ft width 8' x depth 5'

Game Room:

290 sq/ft width 20' 6" x depth 14' 2"

Garage:

823 sq/ft width 34' 4" x depth 24'

Gathering Room:

374 sq/ft width 20' 10" x depth 18'

Hall Bathroom:

20 sq/ft width 4' 6" x depth 4' 6"

Kitchen:

143 sq/ft width 13' x depth 11'

Living Room:

369 sq/ft width 20' 4" x depth 18' 2"

Master Bathroom:

168 sq/ft width 14' x depth 12'

Master Bedroom:

352 sq/ft width 23' 6" x depth 15'

Porch - Front:

121 sq/ft width 11' x depth 11'

Powder Room:

33 sq/ft width 6' 10" x depth 4' 10"

Storage:

97 sq/ft width 8' 4" x depth 11' 8"

Study:

181 sq/ft width 12' 6" x depth 14' 6"

Utility Room:

63 sq/ft width 8' 4" x depth 7' 8"

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
Questions? Call 1-866-445-9085

Plan Set

Reproducible Set:
$1390.00
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
PDF Set:
$3543.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
5 Copy Set:
$4085.00
5 printed plan sets mailed to you.
CAD Set:
$4429.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x6:
$0.00
Wood 2x6

Additional Options

Additional Construction Sets:
$120.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide:
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design:
$200.00
Receive an overlay sheet with suggested placement of lighting fixtures.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
