Key Specs
5073
sq ft
3
Beds
3
Baths
1
Floors
3
Garages
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
PLAN 928-29
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 83'
Height : 38'
Width : 102'
Area
Basement Living: 2289 sq/ft height 9'
First Floor: 2784 sq/ft height 9'
Roof
Primary Pitch : 16:12
Roof Framing : Truss
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Stone/Stucco
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Exercise Room
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Mud Room
Open Floor Plan
Unfinished Future Space
Garage Features
Side Entry Garage
Outdoor Spaces
Courtyard
More
Wheelchair Adaptable
Rooms
Bedroom 2:
203 sq/ft width 14' 6" x depth 14'
Bedroom 3:
209 sq/ft width 18' 1" x depth 11' 7"
Dining Room:
202 sq/ft width 15' x depth 13' 6"
Exercise Room:
152 sq/ft width 11' 8" x depth 13' 1"
Family Dining Room:
190 sq/ft width 19' x depth 10'
Garage:
1225 sq/ft width 25' x depth 49'
Great Room:
313 sq/ft width 19' x depth 16' 6"
Kitchen:
237 sq/ft width 19' x depth 12' 6"
Library:
202 sq/ft width 15' x depth 13' 6"
Master Bedroom:
217 sq/ft width 15' x depth 14' 6"
Porch - Screened:
240 sq/ft width 15' 8" x depth 15' 4"
Recreation Room:
247 sq/ft width 18' 1" x depth 13' 8"
Sitting Area:
133 sq/ft width 12' 2" x depth 11'
What's Included In This Plan Set
Please note: If you are building a Visbeen Architects design in the state of Michigan, please give us a call to confirm availability. Construction in the state of Michigan requires special permission from the Architect.
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Plan Set
$1695.75
$3395.75
Foundation
$0.00
Framing
$0.00
Additional Options
$165.75
$140.25
$420.75
$33.15
$140.25
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
