Plan Description


This gorgeous, brand-new design shows off open living spaces and a luxurious master suite. Unique and thoughtful details include see-through fireplaces in both the living room and the master suite, a private "owner's courtyard," and a bar.

Full Specs & Features


Dimension

Depth : 82'

Height : 32' 6"

Width : 70'

Area

Main Floor : 3281 sq/ft

Porch : 371 sq/ft

Upper Floor : 980 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Upper Ceiling Ft : 9'

Roof

Primary Pitch : 8/12

Roof Framing : Conventional

Roof Type : Metal

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : 2x6

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Upstairs Bedrooms

Walk In Closet

Kitchen Features

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room

Loft

Main Floor Laundry

Mud Room

Storage Area

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

What's Included In This Plan Set


• Floor Plan(s): Detailed plans for each level showing room names, dimensions, wall thicknesses, door and window sizes and locations, kitchen cabinet and appliance configuration, and bathroom plumbing fixture locations. • Exterior Elevations: Views of all four sides of the house showing exterior materials. • Cross Section(s): A vertical cutaway view of the house from roof to foundation. • Interior Elevations: Detailed views of all cabinets, and other elements as required. • Electrical Plan(s): Plan for each level showing the location of lights, fans, electrical outlets, and switches, etc. • Roof Layout: A guide to the geometry of the roof, as well as pitch and overhang details. • Foundation Plan: Thoroughly noted and dimensioned plan showing all necessary footings, piers, columns, and foundation walls. • Ceiling Framing: Plan showing the size and layout of ceiling joists, beams, and headers, as well as the location of load bearing walls. • Roof Framing: Plan showing size and layout of rafters, ridges, hips and valleys, as well as locations of necessary beams and brace points. • Structural Notes and Details: Review details from the engineer. (Plans are not stamped or sealed. Engineer comments or specs are based on review of the plans at the time of design.) • Additional Build Licenses are available for 50% of the PDF plan price. Please call for details.
