Plan Description


This mediterranean home brings together classic design and function of today’s lifestyle. A centrally located foyer opens up into a great room. To the right, the master wing features the laundry room, dual linen closets and a study. To the left of the foyer are the stairs to the second level and the 2 car garage entry. Immediately ahead is the open concept kitchen, 2 story dining room, and great room. Beyond the kitchen, a private wing houses a one car garage and a separate guest suite. Upstairs, a large game room separates three additional bedrooms. Two bedrooms share a Jack and Jill bath, while the third shares another bath with the game room.

Full Specs & Features


Dimension

Depth : 68'

Height : 27'

Width : 87'

Area

Garage : 772 sq/ft

Main Floor : 2375 sq/ft

Porch : 518 sq/ft

Upper Floor : 1210 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 11'

Main Ceiling : 10'

Upper Ceiling Ft : 9'

Roof

Primary Pitch : 6:12

Roof Framing : Stick

Roof Type : Concrete tile

Exterior Wall Framing

Exterior Wall Finish : Stone

Framing : 2x4

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Split Bedrooms

Upstairs Bedrooms

Walk In Closet

Kitchen Features

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Great Room Living Room

Hobby Rec Room Game Room

Main Floor Laundry

Mud Room

Play Flex Room

Storage Area

Garage Features

Front Entry Garage

Side Entry Garage

Split Garage

Entryway

Friend S Entry

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
