PLAN 40-112
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 51' 8"
Height : 34'
Width : 70'
Area
First Floor: 2313 sq/ft height 10'
Second Floor: 953 sq/ft
Roof
Primary Pitch : 6:12
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Exterior Wall Framing
Framing : Wood - 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Loft
Storage Area
Garage Features
Detached Garage
Oversized Garage
Rear Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Balcony
Breezeway
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
150 sq/ft width 11' x depth 13' 8"
Bedroom 3:
156 sq/ft width 12' x depth 13'
Bedroom 4:
110 sq/ft width 11' x depth 10'
Breakfast Room:
126 sq/ft width 14' x depth 9'
Dining Room:
156 sq/ft width 12' x depth 13'
Foyer:
273 sq/ft width 14' x depth 19' 6"
Garage:
812 sq/ft width 25' x depth 32' 6"
Gathering Room:
375 sq/ft width 25' x depth 15'
Kitchen:
175 sq/ft width 14' x depth 12' 6"
Living Room:
197 sq/ft width 12' 6" x depth 15' 10"
Master Bathroom:
161 sq/ft width 14' 8" x depth 11'
Master Bedroom:
210 sq/ft width 15' x depth 14'
Porch - Front:
322 sq/ft width 8' x depth 40' 4"
Porch - Left:
163 sq/ft width 11' x depth 14' 10"
Porch - Rear:
72 sq/ft width 7' 4" x depth 9' 10"
Powder Room:
39 sq/ft width 6' x depth 6' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$905.00
$995.00
$1080.00
$1655.00
$805.00
Foundation
$0.00
$0.00
$0.00
Additional Options
$100.00
$50.00
$100.00
$39.00
$200.00
$50.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
