Plan Description


The contemporary style of the Ashbourne’s panel siding and cable rail balconies make for a charming addition to any new development or neighborhood. The wide, expansive nature of this duplex makes it possible for large families to enjoy busy city living. Each unit features a split-level entry and two garage bays each. Sitting on a sloped lot, this plan is more versatile and can fit on a special type of lot that most duplex plans cannot. The lower basement floor encompasses the garage, utility room and a mud hall that is perfect for separating dirty clothes from the main living areas upstairs. The main floor has a unique feature that an ordinary duplex does not; high 12’ ceilings in the primary suite and great room. Towards the rear of the main upper floor are the two additional bedrooms that share a hall bathroom. The kitchen is open to the dining room, being separated by a mere eating bar. The walk-in pantry is a nice touch to each kitchen, and shares a wall with the rear covered porch.

Full Specs & Features


Dimension

Depth : 47'

Height : 29' 2"

Width : 72'

Area

Garage : 1190 sq/ft

Lower Floor : 500 sq/ft

Main Floor : 2554 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Lower Ceiling : 10'

Main Ceiling : 9'

Roof

Primary Pitch : 2/12

Roof Framing : Truss

Roof Load : 25

Exterior Wall Framing

Exterior Wall Finish : Siding/Panel

Framing : 2x6

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Breakfast Nook

Eating Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room

Mud Room

Garage Features

Front Entry Garage

Garage Under

Lot Characteristics

Suited For Sloping Lot

Suited For View Lot

Outdoor Spaces

Balcony

Covered Front Porch

What's Included In This Plan Set


Please note, if ordering a PDF Print Set, it is not-modifiable. The CAD set is best for making local modifications. The "5 set + PDF" combo contains a non-modifiable PDF Print Set. The "8 set + PDF" combo contains a non-modifiable PDF Print Set.

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
  • Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
  • Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
  • Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
  • Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
  • Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
  • Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
  • Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
  • Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
  • Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
