Key Specs
2511
sq ft
3
Beds
3
Baths
2
Floors
2
Garages
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
with Code CTB2025 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 120-111
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 63' 8"
Height : 33'
Width : 54'
Area
First Floor: 1781 sq/ft height 9'
Second Floor: 730 sq/ft
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stone/Stucco
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Additional Room Features
Family Room Keeping Room
Hobby Rec Room Game Room
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
More
Jack & Jill Bath
Rooms
3rd BR Closet:
18 sq/ft width 2' x depth 9' 2"
Basement Foundation:
3438 sq/ft width 54' x depth 63' 8"
Bathroom 2:
40 sq/ft width 8' x depth 5'
Bedroom 2:
147 sq/ft width 12' 6" x depth 11' 10"
Bedroom 2 Closet:
20 sq/ft width 2' x depth 10' 5"
Bedroom 3:
135 sq/ft width 12' 6" x depth 10' 10"
Bedroom 3 Closet:
20 sq/ft width 2' x depth 10' 5"
Breakfast Room:
123 sq/ft width 10' 2" x depth 12' 2"
Crawlspace Foundation:
3438 sq/ft width 54' x depth 63' 8"
Deck:
402 sq/ft width 12' x depth 33' 6"
Dining Room:
151 sq/ft width 11' 8" x depth 13'
Game Room:
151 sq/ft width 11' 8" x depth 13'
Garage:
432 sq/ft width 21' x depth 20' 7"
Garage Storage:
25 sq/ft width 3' 5" x depth 7' 7"
Gathering Room:
357 sq/ft width 18' 2" x depth 19' 8"
Hall Closet:
12 sq/ft width 3' 2" x depth 4'
Kitchen:
227 sq/ft width 14' 6" x depth 15' 8"
Master Bathroom:
137 sq/ft width 11' 9" x depth 11' 8"
Master Bedroom:
217 sq/ft width 15' 6" x depth 14'
Master Closet:
87 sq/ft width 6' x depth 14' 6"
Porch - Front:
55 sq/ft width 5' 6" x depth 10'
Powder Room:
25 sq/ft width 5' 1" x depth 5' 1"
Slab Foundation:
3438 sq/ft width 54' x depth 63' 8"
Utility Room:
44 sq/ft width 6' 1" x depth 7' 3"
What's Included In This Plan Set
- Designer offers a 2nd Build License for $395 with a PDF purchase as well as an Unlimited License for $395 with the purchase of a CAD.
- Floor Plans – ¼”=1’-0” scale floor plan indicating location of frame and masonry walls, support members, doors, windows, plumbing fixtures, cabinets, shelving, ceiling conditions and notes deemed relevant to this plan.
- Exterior Elevations – All elevations at ¼” = 1’-0” scale in most cases. Some older designs may contain 1/8” scale side and rear elevations. Drawing will indicate overall configuration of home at each side view and make note of plate heights, roof overhangs, window header heights, roof pitches, materials used and extent to which they are used and enlargement of any details we feel necessary to explain the construction.
- Building Sections – ¼” = 1’-0” building sections are included when there is no other reasonable way to indicate the volumetric/height conditions in the home. Most of this information can usually be determined from the exterior elevations.
- Cabinet Elevations – 3/8” = 1’-0” scale elevations indicating configuration of cabinets, heights, widths, type of components used, cabinet material and finish, counter surfaces, appliances.
- Framing Plans – ¼” – 1’-0” scale framing plans indicating size and spacing of members as well as bracing and blocking required for structural purposes. Local codes will most likely need to be consulted.
- Foundation Plans – ¼” = 1’-0” scale foundation plans indicating location of structural walls, grade beams, reinforcing steel and structural columns. Consulting a local engineer is advisable as well as is analysis of soil conditions on site.
- Electrical Plans – ¼” = 1’-0” scale schematic plans indicating location and types of electrical fixtures, switches, outlets, and how they are to be switched.
Plan Set
$1545.00
$1745.00
$1845.00
$2240.00
$2540.00
$2545.00
Foundation
$0.00
$195.00
$395.00
$495.00
Framing
$0.00
$345.00
Additional Options
$245.00
$60.00
$695.00
$165.00
$295.00
$39.00
$165.00
$695.00
$295.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
