PLAN 301-155
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 89'
Height : 28'
Width : 40' 6"
Area
First Floor: 1923 sq/ft
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Stucco
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Open Floor Plan
Storage Area
Garage Features
Side Entry Garage
Outdoor Spaces
Courtyard
Covered Rear Porch
Rooms
3rd BR Closet:
13 sq/ft width 2' x depth 6' 8"
Bathroom 2:
50 sq/ft width 5' x depth 10'
Bedroom 2:
147 sq/ft width 11' x depth 13' 5"
Bedroom 2 Closet:
14 sq/ft width 2' x depth 7'
Bedroom 3:
147 sq/ft width 11' x depth 13' 5"
Bedroom 3 Closet:
14 sq/ft width 2' x depth 7'
Dining Room:
192 sq/ft width 16' x depth 12'
Foyer:
30 sq/ft width 5' x depth 6'
Garage:
438 sq/ft width 22' x depth 19' 11"
Garage Storage:
32 sq/ft width 2' 3" x depth 14' 6"
Gathering Room:
224 sq/ft width 14' x depth 16'
Kitchen:
236 sq/ft width 17' 6" x depth 13' 6"
Laundry Room:
52 sq/ft width 5' 10" x depth 9'
Master Bathroom:
120 sq/ft width 13' 5" x depth 9'
Master Bedroom:
227 sq/ft width 15' 2" x depth 15'
Master Closet:
86 sq/ft width 8' 3" x depth 10' 6"
Porch - Rear:
130 sq/ft width 13' x depth 10'
Powder Room:
25 sq/ft width 5' x depth 5'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$945.00
$1050.00
$1050.00
$735.00
Foundation
$0.00
Framing
$0.00
Additional Options
$60.00
$100.00
$39.00
$100.00
$60.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
