PLAN 23-252
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 55'
Height : 26'
Width : 58'
Area
Bonus: 372 sq/ft
First Floor: 1219 sq/ft height 9'
Garage: 755 sq/ft
Second Floor: 809 sq/ft
Roof
Primary Pitch : 6:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x6
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Additional Room Features
Loft
Play Flex Room
Unfinished Future Space
Workshop
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
More
Suited For Vacation Home
Rooms
3rd BR Closet:
24 sq/ft width 3' 10" x depth 6' 4"
Bathroom 2:
81 sq/ft width 11' 8" x depth 7'
Bedroom 2:
136 sq/ft width 11' 8" x depth 11' 8"
Bedroom 2 Closet:
24 sq/ft width 3' 10" x depth 6' 4"
Bedroom 3:
136 sq/ft width 11' 8" x depth 11' 8"
Bedroom 3 Closet:
24 sq/ft width 3' 10" x depth 6' 4"
Bonus Room - Finished:
342 sq/ft width 23' 4" x depth 14' 8"
Dining Room:
147 sq/ft width 11' 8" x depth 12' 8"
Garage:
782 sq/ft width 23' x depth 34'
Kitchen:
140 sq/ft width 10' x depth 14'
Living Room:
276 sq/ft width 12' x depth 23'
Master Bathroom:
93 sq/ft width 12' 2" x depth 7' 8"
Master Bedroom:
175 sq/ft width 11' 8" x depth 15'
Master Closet:
44 sq/ft width 5' 10" x depth 7' 8"
Porch - Front:
264 sq/ft width 33' x depth 8'
What's Included In This Plan Set
Plans are typically drawn to ¼” scale and include:
- Foundation Plan(s): Foundation plans typically include: All exterior / interior dimensions, thickness of foundation walls (if variable), all structural details, location of stairwell, location and size of windows and location / dimensions of footings (where applicable and required)
- Floor Plan(s): Floor plans typically include: All interior / exterior dimensions (included but not as a schedule), location and sizes of doors / windows, indication of the structure above (second floor or roof), indication that details are on other pages
- Exterior Elevations: Front, rear, left & right sides) typically include: Floor/ceiling heights, dimensions of standard windows & roof overhangs, location of all needed flashings, height and location of foundation, type of finishing and textures, dimensions of chimney,
- Overhead Roof Plan(s): Roof plans typically include: location of all the different trusses, general overcharge of the roof compared to the floor footprint.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Construction Notes / Detail(s): Details typically include: Roof sections, sections of concrete wall with wood connection, sections of walls with particular called out, section of concrete porch and connection with wood frame, foundation particulars, wall components.
- Wall Section(s): Wall sections typically include: All the details and components needed in construction.
*** Please note that some plans from this designer may be delayed 5-7 days as they are updating plan content. ***
Plan Set
$1406.75
$1525.75
$2256.75
Foundation
$0.00
$361.25
$361.25
$361.25
Additional Options
$212.50
$55.25
$140.25
$250.75
$33.15
$140.25
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
