Plan Description

Gables along the roofline enhance this traditional ranch home. Inside, the foyer opens to the spacious great room and the dramatic dining room, both with cathedral ceilings and lots of glass. The front kitchen and dinette are conveniently located for your family's living needs while the formal entertaining areas are located at the rear of the home. Your guests will dine with warmth from the fireplace. Natural light is abundant throughout the entire house. The master bedroom, featuring a cathedral ceiling, is tucked away to the left of the foyer. Every amenity, from a corner whirlpool tub, glass corner shower and His and Hers vanities, is found in the adjoining private bath.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 43'

Height : 20'

Width : 71'

Area

First Floor: 1724 sq/ft height 8'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 10:12

Roof Framing : Combination Truss/Conventional

Exterior Wall Framing

Exterior Wall Finish : Brick

Framing : Wood - 2x6

Bedroom Features

Fireplace

Formal Dining Room

Split Bedrooms

Additional Room Features

Great Room Living Room

Rooms

3rd BR Closet:

15 sq/ft width 2' x depth 7' 8"

Basement Foundation:

3053 sq/ft width 43' x depth 71'

Bedroom 3:

120 sq/ft width 11' 11" x depth 10' 1"

Bedroom 4:

104 sq/ft width 9' 1" x depth 11' 6"

Bedroom 4 Closet:

11 sq/ft width 2' 1" x depth 5' 8"

Breakfast Room:

114 sq/ft width 12' 6" x depth 9' 2"

Dining Room:

143 sq/ft width 13' 4" x depth 10' 9"

Foyer:

67 sq/ft width 9' 3" x depth 7' 4"

Garage:

419 sq/ft width 21' 4" x depth 19' 8"

Gathering Room:

251 sq/ft width 19' 4" x depth 13'

Hall:

width 3' 2" x depth 0"

Hall Bathroom:

40 sq/ft width 5' x depth 8'

Hall Closet:

6 sq/ft width 2' x depth 3' 2"

Kitchen:

112 sq/ft width 11' 10" x depth 9' 6"

Laundry Room:

42 sq/ft width 5' 4" x depth 8'

Master Bathroom:

101 sq/ft width 8' 10" x depth 11' 6"

Master Bedroom:

199 sq/ft width 13' 4" x depth 15'

Master Closet:

34 sq/ft width 6' x depth 5' 10"
