Plan Description


This 1,323-square-foot house plan shows that you don't need a huge house (or a huge budget) to achieve superb modern style. The interior layout showcases outstanding openness between the family room, dining area, and island kitchen.

Full Specs & Features


Dimension

Depth : 35'

Height : 25' 3"

Width : 47' 8"

Area

Basement : 1323 sq/ft

Main Floor : 1323 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : + 10' in living room

Lower Ceiling : 8'

Main Ceiling : 9'

Roof

Primary Pitch : 11/12

Roof Framing : Truss

Roof Type : Wood

Secondary Pitch : 12/12

Exterior Wall Framing

Framing : 2x6

Bedroom Features

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Kitchen Island

Additional Room Features

Family Room Keeping Room

Mud Room

Garage Features

Carport Porte Cochere

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

More

Economical To Build

What's Included In This Plan Set


*Important* This designer may need 5-7 business days to update the plan content when an order is placed. Please call to confirm your order details.


This plan set typically contains:
Exterior Elevations (front, rear, left & right sides) typically include:
  • Floor and ceiling heights
  • Dimensions of standard windows
  • Dimensions of roof overhangs
  • Location of all needed flashings (mention of “typical” in most cases)
  • Height and location of foundation indicated in dashed lines
  • Type of finishing and textures (we write siding, horizontal or vertical but not the company)
  • Dimension and height of chimney (dimensions yes but the height is determined by the local building code)
Foundation plans typically include:
  • All exterior and interior dimensions
  • Thickness of foundation walls (if variable)
  • All the structures needed to hold the first level, columns with load applications, beam sizes, variations in floor joists and their exact location. (The load application is not present. Same for the beam, we mention they are but not the size because this can be changed as per manufacturer)
  • Location of stairwell
  • Location and sizes of windows
  • Location and dimensions of footings (where applicable and required)
Floor plan(s) typically include:
  • All interior and exterior dimensions (included but not as a schedule)
  • Location and sizes of doors and windows
  • Indication of the structure above (second floor or roof)
  • Indication of details that are available on other pages
Roof plans typically include:
  • Location of all the different trusses needed
  • The general overcharge of the roof compared to the floor footprint underneath
Building cross-section(s) and truss details typically include:
  • All the different floor and ceiling heights
  • Dimensions and design of trusses
  • Dimensions and details of overhand
  • Roof pitch on all truss sections
Construction details typically include:
  • Roof sections
  • Sections of concrete wall with wood connection
  • Section of walls with particulars called out
  • Section of concrete porch and connection with wood frame
  • Foundation particulars in the garage entrance
  • Components of certain types of walls (ex: between garage and living quarters)
Typical wall sections typically include;
  • All the details and components needed in the construction of a house, including window section in a typical wall, connection between floor and exterior wall with their components, type of beam used.
  • Note: This plan does not include HVAC, electrical and plumbing.
