Full Specs & Features
Depth : 30'
Height : 14' 9"
Width : 50'
Main Floor : 1200 sq/ft
Porch : 72 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 6:12
Roof Framing : gable
Roof Type : truss
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : siding
Framing : 2x6
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
